MODELS COVERED:

XL125S (1979-1982, 1984-1985)
XL185S (1979-1983)
XL200R (1983-1984
XR185 (1979)
XR200 (1980-1984)
XR200R* (1981-1983, 1986-1988, 1990-2003)
TLR200 (1986-1987)


This Honda Motorcycle Manual is 368 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Safety first / Expendable supplies / Shop tools / Emergency tool kits / Troubleshooting and tune-up equipment

CHAPTER TWO / TROUBLESHOOTING
Starting difficulties / Poor performance / Clutch and transmission / Drive train / Chassis / Brakes / Electrical system / Charging system / Lighting / Fuses / Wiring

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine checks / Pre-checks / Tires and wheels / Crankcase breather hose (U.S. models only) / Battery (XL series) / Periodic lubrication / Periodic maintenance / Engine tune-up / Storage / General specifications / Serial numbers / Parts replacement

CHAPTER FOUR / ENGINE
Engine principles / Engine cooling / Servicing engine in frame / Engine / Cylinder head cover and camshaft / Camshaft chain / Cylinder head / Valves and valve components / Cylinder / Piston, piston pin and piston rings / Ignition advance and pulse generator / Alternator / Oil pump / Crankcase and crankshaft / Camshaft chain and tensioner / Kickstarter / Break-in procedure

CHAPTER FIVE / CLUTCH AND TRANSMISSION
Clutch / Clutch cable / External shift mechanism / Drive sprocket / Transmission and internal shift mechanism / 5-speed transmission and internal shift mechanism (XL185S) / 6-speed transmission and internal shift mechanism

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Air cleaner / Carburetor operation / Carburetor service / Carburetor adjustments / Throttle cable / Choke cable (XL125S and XL185S) / Fuel shutoff valve / Fuel strainer (XL125S and XL185S since 1982) / Fuel tank / Fuel tank repair (metal tanks only) / Fuel filter / Crankcase breather system (U.S. models only) / Exhaust system

CHAPTER SEVEN / ELECTRICAL SYSTEMS
Charging system (XL125S and XL185S) / Battery / Rectifier (XL series, 1979-1981) / Voltage regulator/rectifier (XL series, 1979-1981) / Voltage regulator/rectifier (XL series, 1982-on) / Alternator / Capacitor discharge ignition / Spark plug / Ignition coil / Ignition pulse generator / Ignition advance mechanism (pulse rotor) / Lighting system / Switches / Electrical components

CHAPTER EIGHT / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Wheels / Tire changing / Tire repairs / Handlebar / Steering head / Front forks

CHAPTER NINE / REAR SUSPENSION
Rear wheel / Rear hub / Driven sprocket assembly / Drive chain / Wheel balancing / Tire changing and tire repairs / Swing arm (dual-shock models) / Swing arm (Pro-Link models) / Shock absorber (dual-shock models) / Pro-Link suspension system / Shock absorber (Pro-Link models) / Pivot arm assembly

CHAPTER TEN / BRAKES
Front and rear brake / Rear brake cable (XR200R) / Rear brake pedal assembly

CHAPTER ELEVEN / FRAME
Kickstand (sidestand) / Footpegs / Frame

SUPPLEMENT TO CHAPTER EIGHT / 1986-2003 XR200R SERVICE INFORMATION

INDEX

WIRING DIAGRAMS
