MOTORCYCLE SERVICE MANUAL

MODELS COVERED:

GL1200 Standard (1984)
GL1200A Aspencade (1984-1987)
GL1200I Interstate (1984-1987)
GL1200L Limited Edition (1985)
GL1200SE-I Aspencade SE-i (1986)

This Honda Gold Wing Manual is 448 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Safety first / Torque specifications / Special tips / Expendable supplies / Parts replacement / Serial numbers / Tune-up and troubleshooting tools /Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Emergency troubleshooting / Engine starting / Engine performance / Engine noises / Excessive vibration / Front suspension and steering / Brake problems /Electrical troubleshooting

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine checks / Pre-checks / Service intervals / Periodic lubrication / Engine oil and filter change / Final drive oil change / Fork oil change / Tune-up / Air filter / Compression test / Carburetor throttle body synchronization / Spark plugs / Ignition timing / Idle mixture / Specifications

CHAPTER FOUR / ENGINE
Hydraulic valve adjuster system / Servicing engine in frame / Removal installation / Camshaft timing belts / Camshaft angel sensor / Camshaft and rocker arm assemblies / Hydraulic tappet / Cylinder heads / Valves and seats / Front and rear cover / Oil pump / Scavenging oil pump / Pulse generator assembly / Alternator / Alternator drive shaft / Starter clutch assembly / Cylinder block / Primary drive chain tensioner / Piston and connecting rods / Crankshaft / Break-in / Specifications

CHAPTER FIVE / CLUTCH AND TRANSMISSION
Master and slave cylinder / Bleeding / External shift mechanism / Primary driven gear / Output shaft / Internal shift mechanism / Specifications

CHAPTER SIX / CARBURETION, EMISSION CONTROL AND EXHAUST SYSTEMS
Carburetor operation service adjustment / Secondary air cutoff valve / Secondary air supply system / Throttle cable / Choke cable / Fuel shutoff valve / Fuel filter / Fuel pump / Fuel tank / Crankcase breather system / Evaporative emission control system / Specifications

CHAPTER SEVEN / FUEL INJECTION SYSTEM
Fuel pressure regulator / Fuel injectors / Air temperature sensor / Coolant temperature sensor / Fuel pump / Electronic control unit / Fuel injection and air chamber assembly / Fuel tank / Specifications

CHAPTER EIGHT / ELECTRICAL SYSTEM
Charging system / Alternator / Voltage regulator rectifier / Ignition system / Ignition control unit / Ignition coil / Pulse generator / Starting system / Lighting system / Switches / Instrument cluster LCD meters / On-board suspension air compressor system / Auto leveling suspension / Electronic travel computer / Cruise control system / Specifications

CHAPTER NINE / COOLING SYSTEM
Radiator / Cooling fan / Thermostat / Water pump / Coolant pipes / Hoses / Specifications

CHAPTER TEN / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Handlebars / Steering head and stem / Steering head bearing race / Front fork / Anti-dive front suspension / Specifications

CHAPTER ELEVEN / REAR SUSPENSION AND FINAL DRIVE
Rear wheel / Rear hub / Final drive unit and drive shaft / Universal U joint / Swing arm / Shock absorbers / Specifications

CHAPTER TWELVE / BRAKES
Brake pad / Disc brakes / Master cylinder / Caliper / Brake hose and line / Bleeding the system / Rear brake pedal / Specifications

CHAPTER THIRTEEN / FRAME AND BODY
Kickstand (sidestand) / Centerstand / Footpegs / Passenger foot rests (ASpencade, Aspencade SE-i and Limited models) / Seat / Hand rail (Standard models) / Top compartment / Rear fender / Windshield / Front fairing and mounting bracket / Saddlebag / Travel trunk / Engine guard / Specifications

INDEX

COLOR WIRING DIAGRAMS
