MODELS COVERED:

Vulcan 1500 Classic D1-D2 (1996-1997)
Vulcan 1500 Classic E1-E7 (1998-2004)
Vulcan 1500 Classic N1-N8 (2000-2008)
Vulcan 1500 Classic T6 (2006)
Vulcan 1500 Drifter J1-J2 (1999-2000)
Vulcan 1500 Drifter R1-R5 (2001-2005)
Vulcan 1500 Nomad G1, G1A, G2A, G3 (1998-2001)
Vulcan Nomad L1-L5 (2000-2004)

This Kawasaki Vulcan 1500 Motorcycle Manual is 448 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Washing the bike / Special tips / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Gasket remover / Threadlocking compound / Expendable supplies / Serial numbers / Warning and information labels / Basic hand tools / Precision measuring tools / Special tools / Fabricating tools / Mechanic’s tips / Ball bearing replacement / Seals / Riding safety / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Starting the engine / Emergency troubleshooting / Engine starting troubleshooting / Engine performance / Engine noises / Engine lubrication / Clutch / Gearshift linkage / Transmission / Electrical troubleshooting / Test equipment / Basic test procedures / Electrical problems / Charging system troubleshooting / Ignition system troubleshooting / Starter system troubleshooting / Carburetor troubleshooting / Excessive vibration / Front suspension and steering / Brake problems / Specifications

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Tune-up /Air filter / Engine oil and filter / Idle speed adjustment / Spark plugs / Battery / Compression test / Ignition timing inspection / Brake system / Clutch system / Cooling system / Fuel hose inspection / Emission control systems / Throttle cable operation and adjustment / Control cable lubrication / Gearshift pedals / Tires and wheels / Lights and horn inspection / Sidestand switch and ignition cut-off system / Steering head bearing inspection / Front suspension inspection / Rear suspension inspection / Swing arm bearing lubrication / Final drive unit / Speedometer cable lubrication / Fasteners / Specifications

CHAPTER FOUR / ENGINE TOP END
Shop cleanliness / Engine / Rocker case cover / Rocker case / Camshaft and cam chain tensioner / External oil hoses / Cylinder head / Valves / Cylinder / Piston and piston rings / Specifications

CHAPTER FIVE / ENGINE LOWER END END
Right crankcase cover / Left crankcase outer cover / Front bevel gearcase / Bevel gears / Driven gear / Primary drive gear and water pump drive mechanism / Starter gears / Oil pump / Balancer weights / Balancer drive gear / Balancer shaft / Crankcase / Crankshaft and connecting rods / Break-in / Specifications
