MODELS COVERED:

FLSTF /FLSTFI Fat Boy (2000-2005)
FLSTFI Fat Boy 15th Anniversary Edition (2005)
FXST/FXSTI Softail Standard (2000-2005)
FXSTD / FXSTDI Softail Deuce (2000-2005)
FLSTN / FLSTNI Softail Deluxe (2005)
FLSTSC / FLSTSCI Softail Springer Classic (2005)
FLSTS/FLSTSI Heritage Springer (2000-2004)
FLSTC / FLSTCI Heritage Softail Classic (2000-2005)
FXSTB / FXSTBI Night Train (2000-2005)
FXSTS / FXSTSI Springer Softail (2000-2005)
FXSTDSE2 Screamin’ Eagle Deuce (2004)
FLSTFSE Screamin’ Eagle Fat Boy (2005)

This Harley-Davidson Motorcycle Manual is 640 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Basic tools / Special tools / Precision measuring tools / Electrical system fundamentals / Basic service methods / Storage / Specifications
