MODELS COVERED:

XVZ13A Royal Star Boulevard (1996-2001)
XVZ13LT Royal Star Tour Deluxe (1997-2001)
XVZ13AT Royal Star Tour Classic (1996-2000)
XVZ13TF Royal Star Venture (1999-2010)
XVZ13CT Royal Star Tour Deluxe (2005-2010)
XVZ13TFL Venture (2011-2013)

This Yamaha Royal Star manual is 536 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Basic tools / Precision measuring tools / Electrical system fundamentals / Special tools / Basic service methods / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Engine principles / Operating requirements / Starting the engine / Starting difficulties / Engine performance / Engine noises / Engine lubrication / Engine leakdown test / Clutch / Gearshift linkage / Transmission / Final drive / Carburetor / Fuel pump / Carburetor heater / Electrical test equipment / Basic electrical test procedures / Electrical systems / Self-diagnostic system / Engine indicator light (all models) / SET/RES lights (XVZ13TF models) / Cruise control / Audio system (XVZ13TF models) / Front suspension and steering / Brake system / Specifications

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Maintenance intervals / Periodic lubrication / Engine oil and filter change / Engine oil pressure test / Battery / Tune-up / Air filter / Spark plugs / Engine compression test / Ignition timing / Valve clearance adjustment / Specifications

CHAPTER FOUR / ENGINE TOP END
Servicing engine in the frame / Cylinder head covers / Camshafts / Cylinder heads / Valves and valve components / Specifications

CHAPTER FIVE / ENGINE LOWER END
Servicing engine in the frame / Engine removal and installation / Cylinder covers / Crankcase breather cover / Alternator cover / Stator and pickup coils / Flywheel / Starter clutch / Starter gears / Oil pan / Oil pump / Main oil gallery / Piston/connecting rod assembly / Pistons and piston rings / Crankcase / Crankshaft and cam chain / Balancer shaft (XVZ13TF models) / Break-in / Specifications

CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM
Bleeding / Fluid draining / Clutch cover / Master slave cylinder / Floorboard shift pedal assembly / External shift mechanism / Clutch hose replacement / Specifications

CHAPTER SEVEN / TRANSMISSION, MIDDLE GEAR AND INTERNAL SHIFT MECHANISM
Internal shift mechanism / Middle gearcase cover / Middle drive gear assembly / Middle driven gear assembly / Specifications

CHAPTER EIGHT / AIR/FUEL, EMISSION CONTROL AND EXHAUST SYSTEMS
Fuel tank / Fuel valve / Fuel filter / Fuel pump / Air filter housing / Surge tank / Carburetor operation / Carburetor / Cleaning, inspection and adjustment / Pilot screw / Throttle position sensor TPS / Carburetor heater system / Throttle cable / Air induction system / Evaporative emission control / Exhaust system / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Electrical connector identification / Battery negative terminal / Charging system / Stator / Voltage regulator rectifier / Ignition system / Ignition coil / Pickup coil / Spark plug / Igniter unit / Starting circuit cutoff relay / Starting system / Starter / Starter relay / Headlight / Meter assembly / Taillight / Brake light / Neutral indicator light / Turn signals / Flasher relay / Horn / Indicator lights / Cruise control / Audio system / Switches / Speed sensor circuit continuity / Fuses / Specifications

CHAPTER TEN / COOLING SYSTEM
Hoses and clamps / Cooling system check / Water pump / Coolant reservoir / Radiator / Fan motor assembly / Thermo unit / Thermostat housing / Thermoswitch / Specifications

CHAPTER ELEVEN / WHEELS AND TIRES
Motorcycle stand / Brake rotor protection / Wheel inspection / Front wheel / Front hub / Rear wheel / Rear hub / Wheel balance / Tire repair / Tire changing / Specifications

CHAPTER TWELVE / FRONT SUSPENSION AND STEERING
Front fork / Handlebar / Grip replacement / Steering head / Steering head bearing races / Lower bearing inner race replacement / Specifications

CHAPTER THIRTEEN / REAR SUSPENSION
Shock absorber / Relay arm / Swing arm / Final gearcase / Specifications

CHAPTER FOURTEEN / BRAKES
Brake service / Brake bleeding and draining / Brake pad replacement / Front brake caliper / Front brake master cylinder / Rear brake caliper / Rear brake master cylinder / Floorboard brake pedal assembly / Brake disc / Brake hose replacement / Specifications

CHAPTER FIFTEEN / FRAME
Rider floorboard / Passenger floorboard / Passenger footpeg / Footrest panel / Side cover / Inner cover / Frame neck cover / Seats / Front fender / Rear fender / Saddlebags / Saddlebag guidebars / Trunk / Lower cover / Specifications

INDEX

COLOR WIRING DIAGRAMS
